Numerical modelling with GeoMod SA

At GeoMod, we perform comprehensive numerical simulations using the finite element package ZSoil. This allows us to treat engineering problems globally and analyse geotechnical problems which are too complex for analytical solutions, taking into account physical phenomena such as time dependent soil-structure interaction. By verifying the global equilibrium of a soil-structure system, we take into account unexpected modes which are difficult or impossible to predict by analytical desk-studies.

WE OFFER:

Consulting and project assistance

High qualifications and broad professional experience allow us to work with clients who look for advanced and reliable solutions at any stage of their projects.

We specialize in:

tunnels, underground storage facilities, metro stations, mining
long-term predictions for soil-structure systems
earthquake engineering
shallow and pile foundation
geothermal engineering
earthwork construction and tailings
cut or fill in highways, railroads
landslides and slope stability
dams, river banks and harbours
retaining structures, water-front and excavation systems with complex excavation sequences
hydraulic structures
multi-storey buildings

Numerical modelling and results analysis

We perform 2D & 3D modelling of all kinds of geometry, including data preparation and post-processing of results. We offer numerical simulations with special reference to soil-structure interaction, taking into account:

advanced and reliable modelling of nonlinear behaviour of materials
stress and water field conditions
explicit definition of excavation and construction sequences
water table and water pressure under steady state or transient conditions, including time- dependent boundary conditions
drained and undrained soil conditions
two-phase continuum including the effect of partial saturation
material creep
heat transfer in soil and structures
geotextiles

We use the following methods:

steady-state or consolidation time increment approaches
elasto-plastic models, including nonlinear elasticity, stress history and hardening effects
replacement force, push-over and time history approaches for seismic verifications
parameter reduction-based method for stability control analyses

In our simulations we match constitutive models to correctly describe site-specific soil behaviour. To achieve this, we use and validate advanced models which represent state-of-the-art geomechanics. Models can be customized to meet specific demands of our clients.

We apply the following constitutive models (ZSOIL.PC 2012):

basic elasto-plastic models for soil materials such as Mohr-Coulomb, Drucker-Prager
multi-laminate model for layered media and schists
Hoek-Brown model for rock
advanced hardening models accounting for stress history: Cap, Modified Cam-Clay
advanced Hardening-Soil model which accounts for small strain stiffness (Go), soil stress history (OCR), and pre-failure plasticity (E50) - effects that are indispensible in performance-based design
Sawicki’s and Zienkiewicz’s liquefaction models
elastic and elasto-plastic models for structural elements such as beams, anchors, nails, membranes and shells
van Genuchten formula for soil water retention curve
pile macro element including bending stiffness and pile-soil interface

ZSOIL data preparation

You own ZSOIL and would like to use it to design a project? GeoMod can help you get your project on the right track: Define your problem and send it to us, we'll make a time/cost estimate for your data preparation!

Optimisation and control

Cost and time reduction is crucial in civil engineering. We help our clients achieve the best possible technical and economical performance by:

recommending the assessment of reliable soil parameters that are used in numerical simulations
performing geometric and parametric studies
optimising pile foundation rafts
optimising retaining structures

We carry out controls of geotechnical ventures before, during and after construction, including:

project control with the aid of advanced numerical models
verification of in situ measurements with numerical prediction
back-analysis of geotechnical parameters (updating models during construction)

Advice and Troubleshooting

For those who want to save time and money, we offer complete finite element models which can be interpreted by the clients themselves. We offer troubleshooting in Finite Element-based calculation packages, especially for ZSOIL users. We also provide assistance related to:

the development of finite element models
choice of modelling approaches
choice of constitutive laws
advanced assessment of material parameters

Teaching

With our strong academic background and broad experience in teaching, we offer courses for individuals and workshops for small groups of engineers who are willing to broaden their professional experience in numerical modelling, advanced geomechanics and geotechnical engineering. Our courses are adapted to our clients’ needs and may contain the following topics:

Project assistance
Continuum and Structural Mechanics and Finite Element modelling
Soil-structure interaction
Mechanics of two-phase media
Push over and dynamics
Material constitutive models

We also give lectures in Soil machenics at EPFL, Switzerland (since 2001) and Numerics in Geotechnics & Structures for ZSoil users (since 2007).
